Event Log

The Event Log records key changes made on Zedi Access that have an effect on flow calculations for an individual site location.

Events are automatically created when a Flow Parameter is changed.

Displaying the Event Log

1. Click Event Log in the Well Site Display drop down menu.



The Event Log window opens.

2. The Events are listed in reverse chronological order. Each Event shows the date and time the change was entered, the serial number of the Smart-Alek Field Instrument (if applicable) on the changed site, and which event change occurred.

3. To view past events, enter the desired date range in the Start and End date fields and select Apply.

4. Click Details... to see detailed information for the selected event.

Click Event Log Listing to return to the Event Log.

5. Click Details Report to see the detailed information for all the events currently displayed in the Event log.

Manually Creating an Event in the Event Log

1. In the Event Log window, click Add User Event. The Add Event Details window opens.

2. In the Event window, select the type of event and enter the parameters as required.

3. Click Add This Event.

Click Event Log Listing to return to the Event Log.
