ZCM - Manage Locations
Manage Location Hierarchy
Your account requires the Operations Hierarchy Administration permission to use this feature. Contact your system administrator for further information.
Users with the Operations Hierarchy Administration manage their Location Hierarchy levels. This section contains the procedures for creating, deleting, and renaming Districts, Areas, Fields and Sites within the Location Hierarchy.
Add Location to Hierarchy
1. Click on your company name from the top of the Location Hierarchy.
2. Select 'Add District' from the Location Panel on the right.
3. The Add District form will open.
4. Enter the District Name, District contact information, and billing information.
5. Select 'Save'.
* Only fields marked by a red asterisk are required.
6. To add an Area, select the District name and select Add Area.
7. To add a Field, select the Area name and select Add Field.
Add Site to a Location
- Click on the District, Area or Field you would like to attach the Site to.
- Click 'Add Site'.
Site Name, On Production Date and Identifier
are all required fields.
- Name - is the name of the Site and will appear in the pending analysis assigned to. And it’s Location information - API/DLS/NTS site identifier, time zone, latitude and longitude.
- Facility information - enter the facility code and choose the facility type and subtype.
- On Production Date - when the site started producing.
- Operated - indicates whether your company operates the Site.
- Active - use to indicate if the site is producing or shut-in
- Save - will save the changes you have made to the Site.
Edit Location or Site
Change the name of your location, the contact information or the site information:
1. Click on the level or site and click 'Edit District', 'Edit Area', 'Edit Field' or 'Edit Site'.
2. Make your edits within the form.
3. Click 'Save'.
Delete Location or Site
To remove a location or Site from the Location Hierarchy:
1. Click on the level or site and click 'Edit District', 'Edit Area', 'Edit Field' or 'Edit Site'.
2. Scroll down to the bottom right of the form.
3. Click 'Delete'.
4. Click ‘Proceed’.
IMPORTANT: Any level that is deleted will also delete any levels below it and all of the measurement schematics and sample points attached to them.
